FSP - FSP-CHAMP-1K



FSP CHAMP 1KVA ON LINE UPS-BK

Description

FSP Champ is the high density version of double-conversion online UPS with an output power factor that reaches 0.9 and featured with ECO for energy saving. USB and RS-232 communication ports as standard, with a built-in intelligent slot.


Specification

FSP CHAMP 1KVA ONLINE UPS

FSP Champ is the high density version of double-conversion online UPS with an output power factor that reaches 0.9 and featured with ECO for energy saving. USB and RS-232 communication ports as standard, with a built-in intelligent slot.

Features:
-True double-conversion
-Microprocessor control optimizes reliability
-Input power factor correction
-Output power factor 0.9
-Wide input voltage (120 V - 300 V)
-Converter mode available
-ECO mode for energy saving
-Generator compatible
-Charger capacity expansion to 6A for long-run models
-Smart SNMP (optional) works well with either USB or RS-232 together
-Comprehensive display allows easy monitoring and access of UPS status

Specifications:
-Model: Champ 1K
-Input Capacity: 1000 VA / 900 W
-Input Voltage Range: 100/110/115/120/127VAC or 200/208/220/230/240VAC
-Input Frequency Range: 40Hz ~ 70 Hz
-Output AC Voltage Regulation: ± 1%
-Output Frequency: 50 Hz or 60Hz ± 0.5% (Batt. Mode)
-Output Waveform(Batt. Mode); Pure Sinewave
-Transfer Time: 0 ms (Typical)
-Battery Type & Number: 12V / 9 AH, 2
-Battery Typical Recharge Time: 4 hours recover to 90% capacity
-Noise: Less than 50dBA @ 1 Meter
-Dimensions: 282(L) x 145(W) x 220(H) mm
-Humidity: 20-90% RH @ 0-40 C (non-condensing)
