Specification
TP-LINK 4PORT 300MBPS WIFI ADSL2+ ROUTER
All-in-One Device: ADSL2+ Modem, NAT Router, 4-Port Switch and Wireless N Access Point
Wireless N speed up to 300Mbps makes it ideal for heavy bandwidth consuming or interruption sensitive applications like online gaming, Internet calls and even the HD video streaming
Easy Setup Assistant with multi-language support provides quick & hassle-free installation
Easy one-touch wireless security encryption with the "WPS" button and easy Wi-Fi On/Off button
Specifications:
Hardware Features:
Interface: 4 10/100Mbps RJ45 Ports/ 1 RJ11 Port
Button: 1 Power On/Off Switch/ WPS Button/ Wi-Fi On/Off Button
External Power Supply: 9VDC/0.85A
IEEE Standards: IEEE 802.3, 802.3u
ADSL Standards: Full-rate ANSI T1.413 Issue 2, ITU-T G.992.1(G.DMT), G.992.2(G.Lite), G.994.1(G.hs), G995.1
ADSL2 Standards: ITU-T G.992.3(G.dmt.bis), ITU-T G.992.4(G.lite.bis)
ADSL2+ Standards: ITU-T G.992.5
Dimensions: 195(W) x 130(D) x 35(H) mm
Antenna Type: Omni directional, Fixed
Antenna Gain: 2x5dBi
Wireless Features:
Wireless Standards: IEEE 802.11n, 802.11g, 802.11b
Frequency: 2.400-2.4835 GHz
Transmit Power: <20dBm(EIRP)
Wireless Security: Support 64/128 bit WEP, WPA-PSK/WPA2-PSK/ Wireless MAC Filtering
Software Features:
Quality of Service: QoS Remarking based on IPP/ToS, DSCP and 802.1p
Port Forwarding: Virtual Server, DMZ, ACL(Acces Control List)
VPN Pass-Through: PPTP, L2TP, IPSec Pass-through
Others:
Certification: CE, FCC, RoHS
System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7 or Windows 8, MAC OS, NetWare, UNIX or Linux
Package Contents:
TD-W8961N
External Splitter
RJ11 Telephone Cable
RJ45 Ethernet Cable
Quick Installation Guide
Resource CD
Power Adapter
