Basic
•Screen Size: 23
•Panel Type: AH-IPS
•Color Gamut: 72%
•Color Depth (Number of colors): 16.7M
•Pixel pitch (mm): 0.2652 mm x 0.2652 mm
•Aspect Ratio: 16:9
•Resolution: 1920*1080
•Brightness (cd/m²): 250 cd/m²
•Contrast Ratio: 1000:1
•Contrast Ratio (DFC): 5M:1
•Response Time (GTG): 5ms
•Viewing Angle (CR=10): 178/178
•Lamp Q'ty: White LED 2ch
•Surface Treatment: Hard coating (3H)
Inputs/Outputs
•[Jack Location]-Signal Input: Back
•D-Sub: Yes
•HDMI: Yes
•[Jack Location]-Audio Output: Back
•Headphone Out: Yes
Power
•Power Type (Adapter or LIPS): Adaptor
•Input: 100-240V
•Power: Normal On (Typ.): 21W
•Power Save/Sleep Mode(Max): 0.3W
•DC Off(Max): 0.3W
Frequency
•H-Frequency (Analog): 30~83kHz
•V-Frequency (Analog): 56~75kHz
•H-Frequency (Digital): 30~83kHz
•V-Frequency (Digital): 56 ~ 61kHz
Resolution
•Analog (PC): 1920*1080
•HDMI (Video): 1920*1080
Control Key
•[Key Location]: Bottom
•Key Number (Power Key Included): 6 keys
•Key Type: Tact
•LED Color (On mode): White
•LED Color (Power save mode): White (Blinking)
OSD
•Country (Language): English,German,Frence,Spain,Italy,Sweden,Finland,Portugues,Brazil,Poland,Russia,Greece,Ukraine,China,Japan,Korea,Hindi.
•Number of Language: 17
Special Feature
•Picture Mode: Yes
•Original Ratio: Yes
•DDC/CI: Yes
•HDCP: Yes
•Intelligent Auto (Auto Resolution): Yes
•Key Lock: Yes
•Plug & Play: Yes
•Reader Mode: Yes
•Flicker safe: Yes
•Dual Smart Solution (Dual web, Dual Display, Smart Resolution): Yes
•SUPER Energy Saving: Yes
•SIX Axis Control: Yes
•RTC: Yes
•Off Timer: Yes
Mechanic
•Front Color: Black (High Glossy)
•Back Cover Color: Black Texture
•Stand Color: Black high glossy+texture
•Base Color: Black high glossy+texture
•Others: Black Texture
•Base Detchable: Yes
•Tilt: -3º (front) ~ 20º(rear)
•Swivel: Yes
Dimension( W*D*H)(mm)
•Set (with Stand): 544*188*436
•Set (without Stand): 544*60*332
•Wall Mount: VESA Compatible (75mmx75mm)
Weight(Kg)
•Set (with Stand): 3.2
•Set (without Stand): 2.9
Standard
•TCO 6.0: Yes
•UL(cUL): Yes
•TUV-TYPE: Yes
•FCC-B, CE: Yes
•EPA 6.0: Yes
•EPEAT: Gold
•Windows 8: Win8
Accessories
•Power Cord: Yes
•D-Sub: Yes
