DEEPCOOL - DC-DA500



DC DA 500W 80+ BRONZE ATX 12V PFC PSU-BK

Description

DEEPCOOL DA500N 500W 80+ BRONZE ATX 12V POWER SUPPLY WITH ACTIVE PFC AND FLAT CABLE - BLACK


Specification

WEB LINK: https://www.sonicinformed.co.za/catalogue/main-components-desktop-power-supply-deepcool-desktop-psu/dc-da500;

DEEPCOOL DA500N 500W 80+ BRONZE ATX 12V POWER SUPPLY WITH ACTIVE PFC & FLAT CABLE - BLACK

Features:
-Compliant with Intel ATX12V V2.4
-High reliability with at least 100,000 hour MTBF
-Integrated Active PFC + PWM Combo Controller
-120mm silent fan with temperature control function
-Support Multi-Way SLI / CrossFire + Multi-Core CPUs
-Longer cable design for enhancing cable management
-80 PLUS Bronze certified, achieve up to 85% efficiency

Specifications:
-Model: DA500
-Type: ATX 12V V2.4
-Product Dimension: 150(W) x 140(L) x 86(H) mm
-Output Capacity: 500W
-Input Voltage: 100~240V
-Input Current: 8A
-Input Frequency Range: 45~60Hz
-Fan Size: 120mm Black Fan
-PFC: Active PFC (>0.99)
-Power Good Signal: 100-500ms
-Hold Up Time: >16ms
-Efficiency: 85% Under Typical Load
-Protection: OVP / UVP /SCP / OPP
-Operation Temperature: 0~40 C
-Regulatory: CE / FCC / CCC / CB / EAC / TUV
-MTBF: 100,000 Hours

Cable Connectors:
-Main Power Connector (24Pin) x1
-Main EPS 12V Connector 8(4+4)Pin x1
-PCI-E (6+2)Pin x2
-SATAx3 + 4pin Peripheralx1
-4pin Peripheralx2 + SATAx2

-Weight: 1600g
-Dimensions: (L)27 x (W)10.5 x (H)18.5

What's in the box:
-1x DA500N 500W 80+ Bronze PSU
-1x User Manual
