DC BARONKASE LIQUID ATX Case

MATX Size Supports ATX Motherboard
Tempered Glass Side-panel
Pre-installed Integrated Liquid Cooling System with 120mm Radiator
Combined RGB Lighting System with Manual Controller
All-metal Front Panel

Application For:
Intel Socket (150W) LGA2011-v3/2011/1366/1156/1155/1151/1150
AMD Socket 140W
AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1
Ryzen
APU A12/A10/A8/A6/A4
FX 8/6/4-Core
Phenom II X6/X4/X3/X2
Athlon II X4/X3/X2
Athlon X4

Specifications:
Materials: SPCC (thickness: side panel: 0.7mm, Glass: 4mm, Front panel: 1.2mm)
Product Dimension (LxWxH): 423x215x470mm)
Weight: 10kg (Net Weight), 11kg (Gross Weight)
I/O Panel: 2xUSB3.0 /Audio (HD)x1 /Micx1/ Manual Controller for RGB
Motherboards: ATX/MATX/MINI-ITX
Drive Bays: 3.5/2.5" Drive Bays x2, 2.5" Drive Bays x3
Expansion Slots: 5

Cooling Fans:
Pre-installed: Rear: 1 x 120mm fan, Top: 1x120mm RGB fan
Optional: Front: 2x120mm or 1x140mm, Top: 2x120/140mm, Bottom: 2x120mm in case of PSU installed at top

CPU Cooler Compatibility:
168mm height limit /Liquid Cooler: 120mm radiator liquid cooling system pre-installed at top
Optional: 120mm radiator at rear, 120/240/140/280mm radiator at top

Power Supply Support: ATX PS2 (maximum length: 200mm at bottom, 160m at top)
Graphic Card Clearance: Maximum 340mm length
Water Block Dimensions: 92.5x93x85mm (LxWxH)
Radiator Dimensions: 154x120x27mm (LxWxH) (aluminium material)
Fan Dimensions: 120x120x25mm RGB Fan
Fan Speed: 500±150-1800±10%RPM (4Pin)
Fan Air Flow: 69.34 CFM (MAX)
Fan Noise Level: 17.8¬30dB(A)
Fan Bearing Type: Hydro Bearing
Fan Rated Voltage: 12VDC
Fan Rated Current: 0.32A
Fan Power Consumption: 3.84W
Pump Connector: 3Pin
Pump Operating Voltage: 6¬13.8VDC
Pump Rated Voltage: 12VDC
Pump Speed: 2300±10%RPM
Pump Current: 0.2A (MAX)
Pump Power Consumption: 2.4W
