DEEPCOOL - DC-GAMMAXXC40



DEEPCOOL GAMMAXX C40 CPU COOLER-BK

Description

Gammaxx C40 is only 137mm tall, but the specially designed compact fin and the 92mm powerful fan make it marvelous in performance, able to support chipsets of TDP up to 130W. The heat sink of Gammaxx C40 is designed to lean away from the RAM.


Specification

DEEPCOOL GAMMAXX C40 CPU COOLER BLACK

Gammaxx C40 is only 137mm tall, but the specially designed compact fin and the 92mm powerful fan make it marvelous in performance, able to support chipsets of TDP up to 130W. To avoid interference, the heat sink of Gammaxx C40 is designed to lean away from RAM. 4*?6 mm heatpipes are constructed with Core Touch Technology (CTT) for direct contact on the chipset.

Features:
-Small in size with height of 137mm, using 92mm fan.
-Powerful performance, Compact fin design + powerful fan makes it capable to support chipsets up to TDP 130W.
-Offcenter heatsink structure to avoid interference with RAM.
-4* 6x6mm heatpipes directly in contact with CPU, absorbing and dissipating the heat more efficiently.
-Special backplate bracket and metal adapter frame makes the mounting easy and structure strong.

Application For:
-Intel LGA20XX/1151/1150/1155/1200/LGA1366
-AMD AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1

Technical Spec:
-Product Dimension: 92×83.8×137 mm
-Heatsink Dimension: 92×58.5×137 mm
-Net Weight: 595 g
-Heatsink Weight: 377 g
-Heatpipe: Ø6 mm×4 pcs
-Fan Dimension: 92×92×25 mm
-Fan Speed: 500~2000 RPM±10%
-Fan Airflow: 33 CFM
-Fan Air Pressure: 2.31 mmAq
-Fan Noise: =23.9 dB(A)
-Fan Connector: 4-pin PWM
-Bearing Type: Hydro Bearing
-Fan Rated Voltage: 12 VDC
-Fan Rated Current: 0.06 A
-Fan Power Consumption: 0.72W
