COOLER MASTER - MPE-7001-ACABW



COOLER MASTER MWE 700W 80+ WHT 230V PSU

Description

The MWE White offers 80+ Standard certification, guaranteeing an average efficiency of 85% at typical load. The DC-to-DC + LLC circuit design allows the unit to convert power from the single +12V rail reliably, efficiently.


Specification

CM MWE SERIES 700W 80+ WHITE 230V PSU

Cooler Master MWE White offers 80+ Standard certification, guaranteeing an average efficiency of 85% at typical load. The thermally sensitove HDB fan cools based on temperature, adjusting constantly as the system's needs change.

Features:
-Power comes from a single +12V source, ensuring consistent output through all cables
-120mm HDB fan employs responsive fan speed control, limiting noise to specific cooling requirements
-The Dc-to-DC + LLC circuit design offers reliable, stable output to all connected components
-The fan will not spin under lower loads or in standby mode, ensuring a quiet user experience during casual operation
-Flat cables take up less space and are easier to manipulate within the chassis

Specifications:
-ATX Version: ATX 12V V2.52 Active PFC
-Input Voltage: 200-240V 50-60Hz 5A
-Fan: 120mm HDB bearing @1500RPM
-Noise @ 100%: 31.2dB-A
-Efficiency: 85% Typically
-Operating Temperature: 40 C optimal
-Power Good Signal: 100-500ms
-MTBF: >100,000 hours
-Protections: OVP/OPP/SCP/UVP/OTP

Connectors:
-ATX 24 Pin x1
-EPS 4+4 Pin x1
-SATA x6
-Peripheral 4 Pin x3
-PCI-e 6+2 Pin x4
