UGREEN - UG-VGA-60533



UG 60533 VGA+AUD EXTENDER VIA CAT5E/6-GY

Description

UGreen 60533 VGA Video Extender Via Single CAT5e/6 Cable Upto 100m Length and Built-in 3.5mm Audio Port - Grey


Specification

WEB LINK: https://www.sonicinformed.co.za/catalogue/automation-intelligent-systems-industrial-computer-peripherals-accessories-cables-and-adaptors-adaptor/ug-vga-60533;

UGreen 60533 VGA Video Extender Via Single CAT5e/6 Cable Upto 100m Length and Built-in 3.5mm Audio Port - Grey

Features:
-Plug and Play
-Industrial metal case
-Integrated 3.5mm audio port
-Support VGA/RJ45 port hot-swap
-Support resolution up to 1080P@60Hz
-Support VGA I/O 26AWG cable up to 20m
-Extend VGA signal upto 100m via LAN cable

Specifications:
-Model No: CM250-60533
-Transmitter I/O: 1x VGA + RJ45 female port
-Receiver I/O: 1x VGA + RJ45 female port
-With 3.5mm audio port, transmission only supports mono
-Resolution support: 1920x1080p@60Hz, backwards compatible with 768p, 720p, 600p, 480p
-Wire gauge required: CAT5/5E or above pure copper LAN cable and AWG26 VGA cable
-Ethernet cable extension length: 1920x1080p@60Hz <100m CAT5E Cable
-VGA output cable length: 1920x1080p@60Hz <10m AWG26 VGA Cable
-Support MacOS/Windows/Linux

Notes:
-Works with 5V power supply, exceeding range of standard voltage may cause damage to the product / lead to unintended satefy problems
-In order to achieve the best performance of the product, it is recommended to use standard pure copper Ethernet cable
-The product cannot be used for switcher and does not support cascade connection
-When the product is not used, please turn off the power or unplug the power supply to avoid potential safety problems caused by leakage

-Weight: 350g
-Dimensions: (L)20 x (W)14 x (H)3cm

What's in the box:
-1x UGreen Transmitter
-1x UGreen Receiver
-2x 5V/1A Power Adapters
-1x User Manual
