ADVANTECH - TPC-1840WP-T3AE



TPC-1840WP-T3AE

Description

With brand-new ID design, the TPC-1840WP provides a high resolution 18.5" display and PCT multi-touch in 16:9 wide format. By embedding an AMD T56E 1.65GHz processor with independent GPU, the TPC-1840WP can support advanced graphical performance in more complex applications. Built-in function and home key button for greater user usability and operating safety. The TPC-1840WP also supports a mini-PCIe slot for communication function expansion. The opening side cover is designed for easy maintenance of Cfast/ HDD/Mini-PCIe components.


Specification

TPC-1840WP-T3AE Specs

General/BIOSAMI 32Mbit
General/CertificationsBSMI, CCC, CE, FCC Class A, UL
General/Cooling SystemFanless design
General/Dimensions488 x 309 x 56.7 (19.21" x 12.17" x 2.23")
General/Enclosure HousingFront bezel: Die-cast Magnesium alloy Back housing: PC/ABS Resin
General/MountingPanel Mount
General/OS SupportMicrosoft® Win8/WES7P/XP/WES2009/Linux
General/Power Consumption35 W (typical)
General/Power Input18 ~ 32 VDC
General/Watchdog Timer1 ~ 255 sec (system)
General/Weight (Net)7kg (15.44 lbs)
System Hardware/ChipsetAMD A50M FCH
System Hardware/CPUAMD G-series T56E 1.65GHz
System Hardware/Expansion SlotsFull-sized Mini PCI-E x 1
System Hardware/LAN10/100/1000Base-T x 2
System Hardware/Memory4GB SO-DIMM DDR3 SDRAM
System Hardware/StorageCFast slot x 1, 2.5" SATA HDD x 1(optional)
System Hardware/I/ORS-232 x 3, RS-422 / 485 x1, USB 2.0 x 2(Host), HDMI x 1, Mic in x 1, Line out x 1
LCD Display/Backlight Life50,000 hrs
Display/Size18.5"
LCD Display/Display TypeWXGA TFT LED LCD
LCD Display/Luminance (cd/m2)300
LCD Display/Max. Colors16.7 M
LCD Display/Max. Resolution1366 x 768
LCD Display/Viewing Angle (H/V°)170/160
Touchscreen/Resolution4096 x 4096 dot
Touchscreen/Touch TypeProjected capacitive
Touchscreen/Light Transmission=88%
Environment/Humidity (Operating)10 ~ 95% RH @ 40°C, non-condensing (Note: Tested for 48hrs)
Environment/Ingress ProtectionFront panel: IP66
Environment/Temperature (Operating)0 ~ 55°C (32 ~ 131°F)
Environment/Temperature (Storage)-20 ~ 60°C (-4 ~ 140°F)
Environment/Vibration ProtectionWith HDD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration)
Environment/Operating Temperature0 ~ 55°C (32 ~ 131°F)
Environment/Storage Temperature-20 ~ 60°C (-4 ~ 140°F)
Environment/Humidity10 ~ 95% RH @ 40°C, non-condensing (Note: Tested for 48hrs)
Touchscreen/TypeProjected capacitive
