With a high quality TPC product line, TPC extends its Touch Panel Computer family with Intel® Atom™ platform for 5.7", 12.1",15" and17". TPC thin client is designed with Intel® Atom™ 1.6 GHz processor as its core. The Intel® Atom™ has low power consumption and 1.6 GHz operating frequency. This system is fanless, slim design for Web-based terminal solutions, so JavaScript is included in the Windows operating system. For Linux systems, we provide Mozilla Firefox.


TPC-1550H-N2BE Specs

Display/TypeXGA TFT LCD
Display/Viewing Angle (H/V°)160/140
Display/Backlight Life (hrs)50,000 hrs
Display/Luminance (cd/m2)350
Display/Max. Resolution1024 x 768
Display/Max. Colors262 K
Display/Contrast Ratio700:1
General/Power Consumption35 W (typical)
General/Power Input18 ~ 28 VDC
General/Watchdog Timer1 ~ 255 sec (system)
General/MountingDesktop, Wall or Panel Mount
General/CertificationsBSMI, CCC, CE, FCC Class A, UL
General/Dimensions383 x 307 x 59 mm (15.08" x 12.09" x 2.32")
General/BIOSAward® 4 MB
General/Cooling SystemFanless design
General/Enclosure HousingDie-cast aluminum alloy, Back housing: SECC
General/OS SupportMicrosoft® Windows® 7/XPE/WES, Windows CE 5.0/6.0 with Java Script, Linux with Firefox explorer and Java Script plugin
General/Weight (Net)3 kg (6.61 lb)
System Hardware/CPUIntel® Atom™ N270 1.6 GHz
System Hardware/Memory2GB SO-DIMM DDR2 667 SDRAM
System Hardware/StorageCFast slot x 1, Optional, external 2.5" SATA HDD kit
System Hardware/ChipsetIntel® 945GSE+ICH7M
System Hardware/LAN10/100/1000Base-T x 2
System Hardware/I/ORS-232 x1, RS-232/422/485 x 1, USB 2.0 x 2 (Host)
Environment/Temperature (Operating)0 ~ 55°C (32 ~ 131°F)
Environment/Temperature (Storage)-20 ~ 60°C (-4 ~ 140°F)
Environment/Humidity (Operating)10 ~ 95% RH @ 40° C, non-condensing
Environment/Ingress ProtectionFront panel: IP65
Environment/Vibration Protection2 Grms (5 ~ 500 Hz)
Touchscreen/Lifespan10 million touches at single point
Touchscreen/Light TransmissionAbove 75%
Touchscreen/Touch Type5-wire, analog resistive
Environment/Operating Temperature0 ~ 55°C (32 ~ 131°F)
Environment/Storage Temperature-20 ~ 60°C (-4 ~ 140°F)
Environment/Humidity10 ~ 95% RH @ 40° C, non-condensing
Touchscreen/Type5-wire, analog resistive
