Specification
Totolink 300Mbps Wireless N Router
Complies with IEEE 802.11n/g/b standards for 2.4GHz Wireless LAN
Up to 300Mbps data rate for Wi-Fi network
Advanced MIMO technology enhances the throughput and wireless coverage
Supports DHCP, Static IP, PPPoE(dual access), PPTP(dual access), L2TP(dual access) broadband functions
Provides 64/128-bit WEP, WPA, WPA2 and WPA-Mixed security
Connects to secure network easily and fast using WPS
Supports IP, Port, MAC, URL filtering and Port Forwarding
QoS: Bandwidth Control based on IP/MAC
Multi-SSID allows user to create multiple SSIDs according to their needs
Supports VLAN function for IPTV and other internet services
Universal repeater and WDS function for easy Wi-Fi extension
Supports TR-069 protocol for remove centralized management
Tech Specs:
Hardware Features:
Interface: 4* 10/100Mbps LAN Ports / 1* 10/100Mbps WAN Port
Power Supply: 9V DC/0.5A
Antenna: 2* 5dBi fixed antennas
Button: 1* RST WPS Button / 1* Power ON/OFF Button
LED Indicators: 1* Power / 1* CPU / 1* Wireless / 1* WAN / 4* LAN
Dimensions (L x W x H): 5.8 x 3.0 x 1.0in (147.5 x 76 x 25mm)
Wireless Features:
Standards: IEEE 802.11n / IEEE 802.11g / IEEE 802.11b
RF Frequency: 2.4~2.4835GHz
Data Rate:
802.11n: Up to 300Mbps
802.11g: Up to 54Mbps (dynamic)
802.11b: Up to 11Mbps (dynamic)
EIRP: <20dBm
Wireless Security: 64/128-bit WEP / WPA/WPA2 / WPA-PSK/WPA2-PSK (TKIP/AES)
Reception Sensitivity:
270M: -61 dBm@10% PER
135M: -65 dBm@10% PER
54M: -68 dBm@10% PER
11M: -85 dBM@10% PER
6M: -88 dBm@10% PER
1M: -90 dBm@10% PER
Software Features:
Operation Mode:
Wireless ISP Client Router
Wireless Client
Repeater (Range Extender)
Router
Bridge with AP
Client
Network: VLAN / IPv6
WAN Type: DHCP/ Static IP/ PPPoE (dual access)/ PPTP (dual access)/ L2TP(dual access)
Wireless Function: Multiple SSID / MAC Authentication / Universal Repeater / WDS / WPS
Schedule: Reboot Schedule / Wireless Schedule
Firewall: Mac Filtering / IP Filtering / Port Filtering / URL Filtering / Port Forwarding / DMZ
Management: Firmware Upgrade / QoS / TR-069 config / DDNS / Access control
