INTEL - NUC-I-DC3217BY



INTEL NUC KIT DC3217BY

Description

Legacy Intel NUC Kits. UCFF (4" x 4") Board Form Factor, mSATA SSD. Support 1 Internal Drives. 17W TDP. Mobile Intel QS77 Express Chipset. Intel Core i3-3217U Processor (3M Cache, 1.80GHz)


Specification

INTEL NUC Kit DC3217BY

Specifications:
Essentials:
Product Collection: Legacy Intel Core Processors
Code Name: Products formerly Ivy Bridge
Vertical Segment: Mobile
Processor Number: i3-3217U
Lithography: 22 nm

Performance:
# of Core: 2
# of Threads: 4
Processor Base Frequency: 1.80 GHz
Cache: 3 MB SmartCache
Bus Speed: 5 GT/s DMI
TDP: 17 W

Memory Specifications:
Max Memory Size (dependent on memory type): 32GB
Memory Types: DDR3/L/-RS 1333/1600
Max # of Memory Channels: 2
Max Memory Bandwidth: 25.6 Gbps

Processor Graphics: Intel HD Graphics 4000
Graphics Base Frequency: 350 MHz
Graphics Max Dynamic Frequency: 1.05 GHz
Graphics Output: eDP/DP/HDMI/SDVO/CRT
Intel Quick Sync Video: Yes
Intel InTru 3D Technology: Yes
Intel Flexible Display Interface (Intel FDI): Yes
Intel Clear Video HD Technology: Yes
# of Displays Supported: 3

Expansion Options:
PCI Express Revision: 2.0
PCI Express Configurations: 1x16, 2x8, 1x8 2x4
Max # of PCI Express Lanes: 16

Package Specifications:
Sockets Supported: PCBGA1023
Max CPU Configuration: 1
TJUNCTION: 105 C
Package Size: 31mm x 24mm

Advanced Technologies:
Intel Hyper-Threading Technology: Yes
Intel Virtualization Technology (VT-x): Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel 64: Yes
Instruction Set: 64-bit
Instruction Set Extensions: Intel AVX
Intel My WiFi Technology: Yes
4G WiMAX Wireless Technology: Yes
Idle States: Yes
Enhanced Intel SpeedStep Technology: Yes
Thermal Monitoring Technology: Yes
Intel Fast Memory Access: Yes
Intel Flex Memory Access: Yes
Intel Identity Protection Technology: Yes

Security & Reliability:
Execute Disable Bit: Yes
Anti-Theft Technology: Yes
